| Engine |
Model |
170F |
170F |
| Type of the engine |
OHV, petrol |
OHV, petrol |
| Engine displacement(cm3) |
212 |
212 |
| Bore×stroke (mm) |
70×54 |
70×54 |
| Max.speed of the engine(min-1) |
3600 |
3600 |
| Engine idling speed range (min-1) |
1500 |
1500 |
| Max. power of the engine(kW) |
4.3 |
4.3 |
| Rate power of the engine(kW) |
4 |
4 |
| Volumes of oil tank (L) |
0.6 |
0.6 |
| Volumes of fuel tank (L) |
3.6/6 |
3.6/6 |
| Capacity |
Kind of drive |
Chain driving,V-belt connection |
Chain driving,V-belt connection |
| Type of clutch |
tensioner |
tensioner |
| Working width (mm) |
800~1000 |
500~800 |
| Working depth (mm) |
150-300 |
150-300 |
| Weight (kg) |
85/95 |
80/90 |
| Dimension(mm)（L×W×H） |
1530*620*1035 |
1630*660*870 |
